| 🔹 Dual-Purpose Design (2-in-1) |
| Cuts both metal sheets and tubes (round, square, rectangular, angle, channel). |
| Saves floor space and investment in separate machines. |
| 🔹 High-Power Fiber Laser Source |
| Available from 1kW to 12kW+ (Raycus / MAX / IPG / nLIGHT). |
| Clean, burr-free cuts on materials like mild steel, stainless steel, aluminum, copper, and brass. |
| 🔹 CNC Controller with Nesting Software |
| Advanced systems like FSCUT3000S, CypCut TubePro, or Beckhoff. |
| Supports tube cutting patterns, hole arrays, notch cutting, and chamfering. |
| 🔹 Automatic Tube Clamping System |
| Pneumatic or electric chucks for fast loading and rotation. |
| Supports round, square, and oval profiles with high centering accuracy. |
| 🔹 Auto-Focus Cutting Head |
| Automatically adjusts focal position based on material thickness. |
| Brands: RayTools / Precitec / WSX |
| 🔹 High Cutting Accuracy |
| Positioning accuracy: ±0.02 mm |
| Repeatability: ±0.01 mm |
| 🔹 Dual Table or Shuttle System (Optional) |
| Enables simultaneous loading/unloading and cutting. |
| Boosts production efficiency for high-volume jobs. |
| 🔹 Safety and Dust Control |
| Fully enclosed or semi-enclosed options with fume extraction and dust filters. |
| Feature / Model | STL-3015R | STL-6020R Pro | STL-6025REX |
| Sheet Cutting Area | 3000 × 1500 mm | 6000 × 2000 mm | 6000 × 2500 mm |
| Tube Cutting Length | Up to 3000 mm | Up to 6000 mm | Up to 6000 mm |
| Max Tube Diameter | Ø160 mm | Ø220 mm | Ø240 mm |
| Laser Power Options | 1kW / 2kW / 3kW | 3kW / 6kW / 8kW | 6kW / 12kW |
| Laser Source Brand | Raycus / MAX | MAX / IPG | IPG / nLIGHT |
| Cutting Speed (Sheet) | Up to 60 m/min | Up to 90 m/min | Up to 120 m/min |
| Cutting Speed (Tube) | Up to 60 rpm | Up to 100 rpm | Up to 120 rpm |
| Auto Focus Head | RayTools (Standard) | Precitec / RayTools | Precitec ProCutter |
| Tube Chuck Type | Pneumatic Manual | Full Electric Servo Chucks | Servo + Auto Centering Chucks |
| Controller Software | FSCUT2000 + TubePro | FSCUT3000S + TubePro | Beckhoff + Custom Nesting |
| Positioning Accuracy | ±0.03 mm | ±0.02 mm | ±0.01 mm |
| Enclosure Type | Semi-Enclosed | Fully Enclosed (Optional) | Fully Enclosed |
| Dimensions (L×W×H mm) | 8200 × 2300 × 2200 | 12500 × 2500 × 2300 | 13200 × 2800 × 2400 |
| Machine Weight | 6000 kg | 9500 kg | 12000 kg |
Sheet and Tube Laser Cutting Machines combine the power of flat sheet cutting with integrated tube and pipe cutting capabilities — all in a single, multi-functional machine. Designed for versatility and high efficiency, these machines allow fabricators to cut metal sheets, round tubes, square pipes, angle iron, and channel steel with a high degree of precision.
