| 1. Robust & Rigid Construction |
| Heavy-duty welded steel frame ensures long-term structural stability. |
| Stress-relieved and precision-machined components reduce deflection during bending. |
| Designed for high repeatability and consistent results under full load. |
| 2. Advanced CNC Control System |
| Equipped with leading CNC controllers (e.g., Delem, ESA, Cybelec) offering: |
| 2D/3D bending simulation |
| Touchscreen HMI for intuitive programming |
| Real-time diagnostics and error alerts |
| Supports CAD/CAM integration, DXF import, and Industry 4.0 protocols. |
| 3. Multi-Axis Back-Gauge System |
| Precision-controlled X, R, Z1, Z2 axes for accurate sheet positioning. |
| Servo-driven ball screw mechanism ensures ±0.01 mm repeatability. |
| Programmable gauge stops for multi-bend operations. |
| 4. High-Performance Hydraulic or Servo Drive |
| Electro-hydraulic synchronized Y1-Y2 axes for smooth, balanced ram motion. |
| Optional hybrid or servo-electric systems for energy efficiency and quiet operation. |
| Variable bending speeds optimize cycle time and reduce tool wear. |
| 5. Automatic Crowning System |
| Hydraulic or mechanical crowning compensates for deflection in the press beam. |
| Maintains angle consistency across the entire bending length. |
| Reduces rework and ensures first-piece accuracy. |
| 6. Quick Tool Clamping System |
| Fast and safe manual, pneumatic, or hydraulic clamping for upper and lower tools. |
| Compatible with Euro-style or Amada-style punches and dies. |
| Optional automatic tool changers for high-mix, low-volume environments. |
| 7. Smart Bending Capabilities |
| Real-time angle correction via optional laser angle measurement systems. |
| Bending sequence optimization to reduce material handling. |
| Integrated bend allowance and spring-back compensation. |
| 8. Safety & Compliance |
| Equipped with advanced safety systems: |
| Laser safety guards or light curtains |
| Emergency stop systems |
| CE/ISO compliant safety interlocks |
| Ensures operator safety without compromising productivity. |
| 9. Energy Efficiency |
| Intelligent pump systems reduce energy usage by up to 50%. |
| Idle mode and low-noise operation reduce environmental impact. |
| Long-lasting hydraulic systems with minimal maintenance. |
| 10. Modular & Tandem Configurations |
| Available in sizes from 40 to 1000+ tons, and 1 to 8+ meters bending length. |
| Tandem press brake options for long parts or synchronized operation. |
| Customizable to suit aerospace, automotive, HVAC, and metal fabrication industries. |
| 🔧 Optional Add-ons & Accessories |
| Sheet followers and lifting aids |
| Robotic integration for automated bending |
| Offline programming software |
| Barcode scanning for job recall |
| Feature / Model | PB-40T/1600 | PB-100T/3200 | PB-160T/4000 |
| Press Capacity | 40 Tons | 100 Tons | 160 Tons |
| Bending Length | 1600 mm | 3200 mm | 4000 mm |
| Distance Between Frames | 1300 mm | 2600 mm | 3400 mm |
| Stroke Length | 120 mm | 160 mm | 200 mm |
| Throat Depth | 200 mm | 320 mm | 400 mm |
| Open Height | 380 mm | 480 mm | 600 mm |
| Back Gauge Range | 500 mm | 600 mm | 750 mm |
| CNC Controller | E21 / DA41 / DA66T (Optional) | DA52 / DA66T | DA66T / Cybelec / ESA |
| Axis Configuration | 2+1 Axis (Y, X + R Optional) | 3+1 Axis | 4+1 Axis |
| Main Motor Power | 4 kW | 7.5 kW | 11 kW |
| Hydraulic System | Rexroth / Bosch | Rexroth / Bosch | Hoerbiger / Yuken |
| Machine Weight | 2,500 kg | 6,500 kg | 9,800 kg |
| Dimensions (L×W×H) | 2200 × 1300 × 2100 mm | 3900 × 1800 × 2400 mm | 4900 × 2100 × 2600 mm |
| Safety Features | Light Curtain, Foot Pedal | Light Curtain, Emergency Stop | Laser Guarding, Safety PLC |
| Optional Features | CNC Crowning, R-axis | CNC Crowning, 2D Graphic CNC | CNC Crowning, Hydraulic Clamps |
| Price Range | $$ | $$$ | $$$$ |
